PTFE Tube
Home
PTFE Tube

Advanced Fluro Pvt Ltd is ISO 9001:2015 certified PTFE Tube manufacturer and supplier since 2011. We manufacture flexible PTFE tubes. Ranging from 0.8 mm to 25 mm OD and 0.25mm to 3 mm wall thickness.

PTFE Tube Specifications

We manufacture flexible PTFE tubes.. The PTFE tubes are manufactured in continuous lengths spanning from 20 to 300 meters depending on the OD & ID of the PTFE tube. We also manufacture PTFE rods or PTFE monofilaments of 1 to 4 mm diameters. These PTFE monofilaments are used in sealing applications.

Kindly get in touch with us for more information about PTFE Tubes.

As a PTFE tube manufacturer, we maintain an extremely tight tolerance to eliminate leakage.

PTFE tubes manufactured by Advanced Fluro maintain their dimension accuracy for each and every PTFE tube coil supplied even for a large order.

As a world class prominent supplier of PTFE tubes, we guarantee the timely manufacturing and delivery of all PTFE tube orders.

Some applications require properties like increased abrasion resistance or self-lubricating PTFE tubes. In such cases, our engineers study the application and come up with solutions to meet application requirements.

For example, many applications require PTFE tubes to have antistatic properties. We manufacture PTFE tubes that meet this requirement.

PTFE Tube

For any inquiries regarding the flexibility and pressure resistance of PTFE tubes, please contact our team via the contact form or by sending an email.

In addition to manufacturing PTFE tubes, we also offer services like sleeving, end flaring, specific cut lengths, etc. In applications where one end of the PTFE tube/sleeve needs to be sealed, our seals are leakproof / water-tight at 25 kg/cm2 pressure during hydro testing. The quality of the seal is a result of technology developed in-house.

Virgin PTFE tubing properties

PROPERTY ASTM Method
Tensile Strength, 73 degrees D638-52T 1,500 – 3,000 lb./sq.in
Elongation 73 degrees Fahrenheit D638-52T 100-200%
Hardness, Durometer D676-49T D50-D60
Coefficient of linear thermal exansion per 73 – 100 degrees Fahrenheit D696-44 5.5 X 10 to the -5 power
Thermal conductivity, 0.18 in Cenco-Fitch 1.7 B.T.U./hr./sq. ft./ degrees Fahrenheit /in.
Heat-distortion temperature 66 lb./sq.in. D6488-45T 250 degrees Fahrenheit
Dielectric strength, short time, 0.080 in. D149-44 400-500 v/mil
Dielectric constant, 60 cycles – greater than 3,000 megacycles D150-54T 2.1
Dissipation factor, 60 cycles – greater than 3,000 D150-54T less then 0.0003
Water-absortion D570-42 less then 0.01%
Flamability D635-44 non-flamable
Specific Gravity D792-50 2.1 – 2.2
Resistance to weathering – Unaffected upto 25 yrs in temperate zones.
Static or kinetic coefficient – 0.04

FAQ’S

We do tubes from about 0.8mm up to 25mm diameter – wall thickness runs 0.25mm to 3mm depending on what you’re after. The smaller rope-style ones (1-4mm) work really well for gaskets and seals. Drop us a line with your specs.
Well, it varies quite a bit. Could be 20 meters, might be 300 – really depends on how thick and wide you want it. The nice thing is you get one continuous piece, so no joints to worry about failing on you later.
We’ve made all sorts over the years. Some customers need them tougher against wear, others want anti-static for electronics work. Had one guy who needed self-lubing ones. Each job’s different, so we just work with what you’re trying to accomplish.
We keep things pretty tight – have to, otherwise you end up with leaks and wasted material. But honestly, every job has its own tolerance needs. Best thing is to talk through your specific application with us.
h, quite a bit actually. We can sleeve existing parts, flare the ends, cut exact lengths. Sometimes people need one end sealed shut – we can do that too. Those seals hold 25 kg/cm² in our pressure tests, which seems to work for most applications.
